Description
With its powerful delivery speed performance that functions under any climate as well as its highly practical and innovative design and features, you can rely on this truck in any situation and terrain.
NAFFCO’s latest FORD RIV equipped with high-tech features is designed for quick rescue and extinguishing fire even in the most stressful situations. Offering impressive extinguishing in high-pressure performance and include Wide range of firefighting accessories and rescue tools.
Equipped with high quality rescue equipment, this truck offers a highly raised telescopic light mast giving 360° visibility during night rescue operations.
Specification
CHASIS
- FORD F-550
- 6.7 L V8 Turbo Diesel
- 10 Speed Select Shift Automatic GVWR 8845 kg
WATER/FOAM TANKS
- Water 1,000 Lit.
- Foam 100 Lit.
- Poly Propylene, UV Stabilized
- Lifetime warranty
FOAM PROPORTIONING SYSTEM
- UL certified NAFFS-AATP
- Automatic ATP Foam System
- Foam ratios 0 -10%, 3% & 6%
NAFFCO CAF SYSTEM
- Compressed air is supplied to the mixing chamber.
- Continuous operation up to 8 mins. based on the number of nitrogen
- Air Automatically controlled by PLC through electronic regulator.
- Air/Foam solution ratio between 1:3 up to 1: 10 as defined in ISO 7076-6.
CAF’S MONITOR
- Shield-UK
- Remotely controlled
- Light alloy construction
- Wet Foam 150 LPM
- Dry Foam 75 LPM
STORAGE LOCKER
- Three RHS storage lockers
- Three LHS storage lockers
- Dust and waterproof
- Automatic illumination
ROOF MONITOR
- Shield-UK
- Remotely controlled
- Light alloy construction
- 2000 LPM at 8 bar
FIRE PUMP
- Shield/UK
- Corrosion resistant
- Rear mounted
- 2,000 LPM at 10 bar
- 250 LPM at 40 bar
- 7.5- 8m Sunction lift
- Automatic Priming System
DCP TROLLEY
- 50 Kg Extinguisher
- 7-9m Range of Discharge
SUSPENSION TIRES
- Lift Kit – 2.5 “ Front and Rear
- Wheels – 20 x 10 Bead Lock Rims
- Fox Shocks – Front and Rear
- Tires – 335/80R20 (MPT 81) – Continental
